This chapter covers how to add basic signals, draw the waveforms for the signals, and how to manage the display and navigate through large numbers of signals.

Later chapters cover more advanced signal types, which calculate their own waveforms or display specialized information:

•Clocks, repetitive waveforms are drawn automatically, are covered in Chapter 2: Clocks.

•Buses and Differential Signals, multi-bit signals, are covered in Chapter 3: Buses.

•Simulated Signals which calculate their waveforms based on Boolean equations, registered logic, and behavioral HDL code are covered in Chapter 4: Simulated Signals.
